Working Process:
Charging—uncoiling—pressing and guiding—pinch preleveler—scrap shear—transitional worktable —guiding—slitting—scrap winding—hydraulic loop bridge —pre-separating—damping pressing—dividing—recoiling—manual baling—discharging.
Major technical parameter
| Item | Parameter | |
|
Coil specification
|
Material | Low carbon steel, Hot roll,
UTS450MPa; |
| Thickness | 1.5mm-5.0mm | |
| Width | 1000mm-1500mm | |
| Coil plate OD. | Φ1000mm-2000mm | |
| Coil plate ID. | Φ508-Φ610mm | |
| Max.Coil weight | 25 tons | |
| Slitting precision | Width tolerance
Vertical tolerance(side bending) Burr |
0.10mm
≤0.8mm/m
≤0.1mm |
| Shearing type | Tensile shear, synchronous shear， | |
| Slitting strip | thickness 1.5-4mm, 12 strips; over 4mm, according to thickness | |
| Recoiling diameter | Φ610mm | |
| Slitting speed | 0-80M/min | |
| Standard height of equipment working surface |
+800mm |
|
